Explosion Proof LED Linear Light - ATEX IECEx Zone 1 Zone 2 - 200W/240W/300W

Applications

Wastewater treatment，oil and gas refineries, drilling rigs, petrochemical facilities, food and beverage facilities, tunnels, outdoor wall and stanchion mounted general area lighting, and where flammable vapors, gases, ignitable dusts, fibers or flyings are present.

Standard :
ATEX: EN IEC 60079-0-2018; EN 60079-7-2015; EN 60079-31-2014;
IECEx: IEC 60079-0-2017; IEC 60079-7-2015; IEC 60079-31-2013;

Warning：

IECEx& ATEX :

• “WARNING – DO NOT OPEN WHEN ENERGIZED”；
• “WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT”；
• “WARNING – Potential Electrostatic Charging Hazard –Please wipe with a damp cloth when cleaning”;
• End user shall use certified cable gland suitable type of protection for final installation purpose；
• External earthing wire shall be connected when used and the cross-sectional area shall be more than 4mm²or 10AWG；
• Under rating condition, maximum temperature on the luminaire’s shell shall not be higher than 165℃ for T3. Temperature at cable inlet shall not be higher than allowable limit of the cable applied, to ensure the cable operation normally. For CES-EX-LN-02-80、CES-EX-LN-02-100、CES-EX-LN-02-120、CES-EX-LN-02-150, the branch point is 78.4℃ and cable entry point is 66.8℃
